Compare & Sync

Pick a source and a target, press Compare, and every object that differs lists in one window. Include the ones to change, generate the script, and read it before anything runs. Requires a Starter license.

​

Opening it

• Database > Compare > Compare & Sync Databases…
• Right-click a connection in the connection list and choose Compare/Sync with…. The connection clicked becomes the source.

The window comes back on the source, target, mode and options it last held, so running the same comparison again is one press of Compare. Opening it from a connection makes that connection the source, and the remembered target comes back only when it was the target of that same source. Every toolbar control also sits under Database > Compare, so the whole flow is reachable from the keyboard.

​

Choosing the two sides

Source and Target are database pickers, not connection pickers: each one walks connection, then database, then schema. Two databases on one server are a valid pair, and so are two schemas in one database. Comparisons in the toolbar lists every saved setup and sets both pickers from the one chosen. It does not need a pair to be chosen first. The source never changes. The target is written to. A connection whose safe mode level is Read-Only is disabled in the target picker with the reason shown, so the refusal arrives at selection time rather than after comparing. Swap reverses the direction. Nothing is written until Apply. Until then the strip along the top reads Comparing only. Nothing has been written.

​

What takes part

Options chooses the object kinds. Tables are always compared; views, materialized views, procedures, functions and triggers are opt-in. Tables are never compared as DDL text. Driver-rendered DDL varies by formatting and by system-generated constraint names, which reports identical tables as different. A routine has no parsed form to compare instead, so its body is the definition, and the normalizer folds line endings, trailing semicolons and, when the options say so, whitespace and identifier case.

​

What is ignored

These drift between environments by design, so they are ignored by default. Turn one off to have the difference reported.

​

Reading the results

Each object lands in one of four states: only in source, only in target, different, or identical. Group By sections the table by difference or by object kind, and the search field filters by name. Identical objects stay hidden until Show Identical Objects. Every row carries an Include checkbox, and a group header carries one for everything under it. Select > All covers everything the pane is currently showing, so the search field and Show Identical Objects narrow what it reaches. Nothing is included until it is checked. An object whose metadata could not be read keeps its own Could Not Compare section with the driver’s reason. One unreadable object never stops the rest of the comparison. The detail pane on the right has three tabs. Definitions shows the source and target side by side, split or unified, rendered from the same function so a formatting difference cannot appear as a real one. Rows is the data comparison. Script is the generated SQL.

​

Comparing rows

Switch the mode control to Data. The left pane lists the tables present on both sides as soon as there is a pair to list them for, without reading a row. Tables start unchecked. Tick the ones to compare, then press Compare: a data comparison reads every row of every ticked table on both sides, so comparing a whole database by accident is expensive. Rows are matched by key, read in key order from both sides and walked in lockstep, so neither side is ever held in memory in full.

​

Setting a table’s scope

Select a table, then set its scope at the top of the Rows tab. Each table keeps its own settings. A filter is a single condition. A semicolon, a comment, or an unclosed quote or parenthesis is refused before either side is read. Press Return or leave the field to apply it.

• A table with no usable key lists as not comparable rather than being matched on a guess.
• A generated column is read and compared but never written. An identity column the target always generates is inserted with OVERRIDING SYSTEM VALUE on PostgreSQL and IDENTITY_INSERT on SQL Server, and never updated.
• NULL equals only NULL. Numeric tolerance applies to numeric columns and timestamp precision to date and time columns, both set in Options.
• A row with NULL in a key column is left out and counted.

​

Row limits and filters

With a row limit, the comparison stops after that many keys in key order. Rows past the limit are not read on either side, so none of them is inserted or deleted. With a filter, a row that matches on one side and exists outside the filter on the other is listed as Outside Filter and never written. Widen the filter to sync it.

​

Reviewing rows

Every column shows in a grid. A row only in the source is underlined, a row only in the target is struck through, and a changed row shows its source line above its target line with each differing value marked. Show narrows the grid to All Rows, Difference, Insert, Update, Delete or Same, plus Outside Filter when a filter produced any. Clear a row’s Include checkbox, or select rows and press Space, to leave them out of the script. The Include menu above the grid includes or excludes every listed row. The grid lists up to 5,000 differences and 1,000 matching rows. Past either cap the pane says so, and Apply still covers every difference.

​

One connection, two databases

A data comparison needs both sides open at once. On an engine that pools connections, two databases on one connection is fine. On an engine that cannot pool, both sides share one driver and one database position, so the comparison refuses that pair by name and asks for a second connection for the target.

​

The script

Generate Script builds the SQL. It is read-only: each statement carries the hazards its operation plan computed, and those cannot be recovered from edited text. Copy and Save… take it elsewhere, and the query editor runs a hand-edited version through the normal path. Statements are ordered by foreign key dependency, not alphabetically. Tables are created parent-first and dropped child-first; row inserts run parent-first and row deletes child-first. A data script is built from a fresh read of both sides. An included table that has not been compared with its current scope holds the script back until it is compared or excluded, and a table whose rows changed since the comparison stops the script with that table named. Compare again, then generate. Script generation needs matching database types, with MySQL and MariaDB counting as one family. A cross-engine pair still compares, read-only: column data types are engine-specific strings, so generating DDL for one engine from another’s metadata is not sound.

​

Applying

Anything that would destroy data is generated, listed, and held back. Dropping a table, dropping a column, narrowing a type, adding NOT NULL, changing a primary key and deleting a row each need an explicit allowance, and that allowance covers one run and is never saved. Apply… opens a sheet with the script, a summary, and the warnings, building the script first when Generate Script has not run. Cancel is the default button and Apply is marked destructive. Allow a held-back statement in the sheet or in the Script pane; the sheet’s Apply stays disabled while any included statement is still held back. On error chooses between stopping and rolling back, stopping and keeping what ran, and skipping and continuing. A transaction cannot be combined with skip and continue, because together they leave the target half-applied. Whether a transaction covers the run depends on the engine. MySQL, MariaDB and Oracle commit implicitly on every DDL statement, so a structure sync on those engines runs without one rather than implying a rollback that will not happen. A data sync into a MySQL or MariaDB table on a storage engine that cannot roll back, such as MyISAM, keeps the rows a rolled-back run already wrote, and the result names those tables. An UPDATE or DELETE that changes more than the one row it was built for counts as a failed statement, and On error decides what happens next. The source, the target, the mode and Options stay locked while a run applies. A target whose connection is switched to Read-Only after it was picked turns Apply off. Closing the window mid-run asks first, and says that statements which already ran stay applied. After a run, press Compare to see where the target stands; the included tables stay checked for the next sync.

​

Saving a comparison

Save Comparison… names the current setup: the source, the target, the mode, the object kinds, the options, the included objects, and each table’s key columns, compared columns, filter and row limit. Rows left out of a script are not saved. It sits in the Comparisons menu and under Database > Compare. Loading one sets both pickers. Comparisons lists them all whatever pair is on screen; Options lists them too, with a Delete for each. A saved comparison whose connection has since been deleted says so instead of loading half a pair.
